DPEW081601 | Driplane Thrust Washer | 1/2 ID x 1 OD x 1/16 THICK
DPEW081201 | Driplane Thrust Washer | 1/2 ID x 3/4 OD x 1/16 THICK
DPEW081602 | Driplane Thrust Washer | 1/2 ID x 1 OD x 1/8 THICK
- SKU / Part Number
- DPEW081601
Warning this product may contain chemicals known by the state of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov
Description / DPEW081601 | Driplane Thrust Washer | 1/2 ID x 1 OD x 1/16 THICK
DPEW081601
DPEW081601 0.5 IN ID x 1 IN OD x 0.0625 IN THICK Dri-Plane Bronze Sintered Thrust Washer
Specifications Catalog Number DPEW081601 Dri-Plane Sintered Bronze Thrust Washer
Material Standard Dri-Plane Powdered Metal Bronze
Tolerances
Inner Diameter Tolerance +0.0010/+0.0020"
Outside Diameter Tolerance +0.0030/+0.0040"
Dry lubricated ideal for applications that cannot have contamination of oil that is associated with most oil impregnated bronze bearings.
Max Temperature 700F
No oil for lubrication, therefore cleaner and no out gassing. Non Magnetic- Max PV 40,000, Max P 1,600 psi, Max V 1,000 sfpm
Standard off-the-shelf dri-plane bronze bearings should function satisfactorily in temperatures up to 700F.
DFARS compliant
Made in the USA
