BBTW056084004 | BB-16 Sintered Iron/Copper Washer | 1-3/4 ID x 2-5/8 OD x 1/8 TH
- SKU / Part Number
- BBTW056084004
Warning this product may contain chemicals known by the state of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov
Description / BBTW056084004 | BB-16 Sintered Iron/Copper Washer | 1-3/4 ID x 2-5/8 OD x 1/8 TH
BBTW056084004
BBTW056084004 1.75 IN ID x 2.625 IN OD x 0.125 IN THICK BB-16 Sintered Iron-Copper Thrust Washer
Specifications Catalog Number BBTW056084004 BB-16 Sintered Iron-Copper P/M Thrust Washer
Material Standard: BB-16 Heat Treated to a particle hardness greater than Rc50
Tolerances
Inner Diameter Tolerance +0.0020/+0.0060"
Outside Diameter Tolerance -0.0020/+0.0080"p>
These oil impregnated thrust washers are impregnated with extreme pressure oil for self-lubricating properties.
Max Temperature 220F
Typically used for heavy loaded applications. These thrust washers have excellent compressive strength, wearability, and shock resistance- Max PV 75,000, Max P 5,000 psi, Max V 35 sfpm
Standard off-the-shelf BB-16 bronze bearings should function satisfactorily in temperatures up to 220F.
DFARS compliant
Made in the USA
