BBEF162216 | BB-16 Sintered Iron/Copper Flanged | 1 ID x 1-3/8 OD x 1 OAL x 1-5/
BBEF162212 | BB-16 Sintered Iron/Copper Flanged | 1 ID x 1-3/8 OD x 3/4 OAL x 1-
- SKU / Part Number
- BBEF162216
Warning this product may contain chemicals known by the state of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov
Description / BBEF162216 | BB-16 Sintered Iron/Copper Flanged | 1 ID x 1-3/8 OD x 1 OAL x 1-5/
BBEF162216
BBEF162216 Flanged BB16 , 1 " ID x 1 3/8 " OD x 1 " OAL 1 5/8 " FLOD x 3/16" FLTH Powdered Metal Copper Iron BB-16
Specifications Catalog Number BBEF162216 BB-16 Sintered Iron-Copper P/M Flanged Bearing
Material Standard: BB-16 Heat Treated to a particle hardness greater than Rc50
Tolerances
Inner Diameter Tolerance +0.0010"/+0.0030"
Outside Diameter Tolerance+0.0020"/+0.0040"
Overall Length Tolerance .005 in
These oil impregnated bushings are impregnated with extreme pressure oil for self-lubricating properties.
Max Temperature 220F
Typically used for heavy loaded applications. These bushings have excellent compressive strength, wearability, and shock resistance- Max PV 75,000, Max P 5,000 psi, Max V 35 sfpm
Standard off-the-shelf BB-16 bronze bearings should function satisfactorily in temperatures up to 220F.
DFARS compliant
Made in the USA
