BBEF121624 | BB-16 Sintered Iron/Copper Flanged | 3/4 ID x 1 OD x 1 1/2 OAL
BBEF121620 | BB-16 Sintered Iron/Copper Flanged | 3/4 ID x 1 OD x 1-1/4 OAL x 1-
- SKU / Part Number
- BBEF121624
Warning this product may contain chemicals known by the state of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov
Description / BBEF121624 | BB-16 Sintered Iron/Copper Flanged | 3/4 ID x 1 OD x 1 1/2 OAL
BBEF121624
BBEF121624 Flanged BB16 , 3/4 " ID x 1 " OD x 1 1/2 " OAL 1 1/4 " FLOD x 3/16" FLTH Powdered Metal Copper Iron BB-16
Specifications Catalog Number BBEF121624 BB-16 Sintered Iron-Copper P/M Flanged Bearing
Material Standard: BB-16 Heat Treated to a particle hardness greater than Rc50
Tolerances
Inner Diameter Tolerance +0.0010"/+0.0030"
Outside Diameter Tolerance+0.0020"/+0.0040"
Overall Length Tolerance .005 in
These oil impregnated bushings are impregnated with extreme pressure oil for self-lubricating properties.
Max Temperature 220F
Typically used for heavy loaded applications. These bushings have excellent compressive strength, wearability, and shock resistance- Max PV 75,000, Max P 5,000 psi, Max V 35 sfpm
Standard off-the-shelf BB-16 bronze bearings should function satisfactorily in temperatures up to 220F.
DFARS compliant
Made in the USA
